| Business Type | Manufacturer, Exporter |
| Flow | UP TO 1800 LPM |
| Head | UP TO 85 MTR |
| Suction X Discharge Size | UP TO 80 MM |
| Click to view more | |
Product Details
Pressure
8.5 KG/CM2
RPM
Pump RPM 2900,1440 RPM
Material Of Construction
CI, SS 304, SS 316, SS 304 L, SS 316 L, CD4MCU
Country of Origin
India
Filtter Press Feeding ,Dyes & intermediates,Slurry Transfer Cake Transfer ETP Plant.Sugar & Food Industries.
Material Construction
| Casing | Flange | Stuffing Box | Bearing Housing | Sealing | Impeller |
| SS 304, SS 316, SS 316 L, ALLOY 20,CD4MCU | As Per 150 CLASS | SS 304, SS 316, SS 316 L, ALLOY 20 ETC | CI | Gland/Seal | CI, SS 304, SS 316, SS 316 L, ALLOY 20,CD4MCU |
.
| Features | Applications |
| Customize material as per application | Filter press feed pump in filter press applicaton |
| Semi open impeller for smooth solid handle size | Scrubber and spray dryer, ETP, slurry transfer |
| More efficent in pipe back pressure handle with expeller design | Filter press, cosmetics, dyes, pigment |
| Dynamic balanced rotating parts | Pulp, paper, sugar |
Performance Chart
| Model | Suc | HEAD IN METER — CAPACITY IN LPM | HP | RPM | ||||||||||||||||||||||||||||
| Dis | Dia | 2 | 4 | 5 | 6 | 8 | 10 | 12 | 14 | 15 | 17 | 18 | 20 | 21 | 24 | 25 | 30 | 32 | 37 | 40 | 42 | 45 | 48 | 55 | 60 | 70 | 75 | 85 | 100 | |||
| GSSP - 4008 | 40x40 | 130 | - | - | 260 | - | - | 244 | - | - | 230 | - | - | 196 | - | - | 0 | - | - | - | - | - | - | - | - | - | - | - | - | - | 2 | 2900 |
| GSSP - 4008 | 40x40 | 148 | - | - | 355 | - | - | 346 | - | - | 328 | - | - | 265 | - | - | 255 | - | 0 | - | - | - | - | - | - | - | - | - | - | - | 3 | 2900 |
| GSSP - 5008 | 50x50 | 170 | - | - | - | - | - | 540 | - | - | - | - | 522 | - | - | - | 505 | - | 458 | - | 110 | 0 | - | - | - | - | - | - | - | - | 5 | 2900 |
| GSSP - 5008 | 50x50 | 178 | - | - | - | - | - | 555 | - | - | - | - | 544 | - | - | - | 517 | - | 460 | - | 300 | - | 0 | - | - | - | - | - | - | - | 7.5 | 2900 |
| GSSP - 6508 | 65x65 | 190 | - | - | - | - | - | 936 | - | - | - | - | 930 | - | - | - | 882 | - | 830 | - | 730 | - | 576 | 0 | - | - | - | - | - | - | 10 | 2900 |
| GSSP - 6508 | 65x65 | 210 | - | - | - | - | - | 990 | - | - | - | - | 982 | - | - | - | 930 | - | 882 | - | 785 | - | - | 618 | 0 | - | - | - | - | - | 12.5 | 2900 |
| GSSP - 650-50LH8 | 65x50 | 235 | - | 1224 | - | - | - | - | - | - | 1212 | - | - | - | - | - | - | 1215 | - | - | - | - | 1164 | - | - | 864 | 492 | 0 | - | - | 25 | 2900 |
| GSSP - 650-50LH8 | 65x50 | 269 | - | 1290 | - | - | - | - | - | - | 1282 | - | - | - | - | - | - | 1275 | - | - | - | - | 1260 | - | - | 1197 | 1135 | - | 756 | 0 | 40 | 2900 |
| GSSP-500L | 50x50 | 178 | - | - | 425 | - | 370 | 322 | 235 | - | 0 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 2 | 1440 |
| GSSP-650L | 65x65 | 210 | - | - | 580 | - | 535 | - | 455 | - | 140 | 0 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 3 | 1440 |
| GSSP-65-50L | 65x50 | 269 | 855 | - | - | 823 | - | 712 | - | 609 | - | 493 | - | - | 263 | 0 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 5 | 1440 |
| GSSP-650L8 | 65x65 | 320 | - | - | - | - | - | 937 | - | - | - | - | 887 | - | - | - | 810 | - | 535 | 0 | - | - | 0 | - | - | - | - | - | - | - | 10 | 1440 |
| GSSP-650L8 | 65x65 | 348 | - | - | - | - | - | 967 | - | - | - | - | 937 | - | - | - | 882 | - | 833 | - | - | 546 | - | - | - | - | - | - | - | - | 15 | 1440 |
| GSSP-650L8 | 80x80 | 264 | - | - | 1800 | - | - | 1750 | - | - | 1660 | - | - | 1415 | - | 333 | 0 | - | - | - | - | - | - | - | - | - | - | - | - | - | 10 | 1440 |
